Ford E-Series | Econoline - Campervan Conversion DIY Kit

To get familiar with attachments points for vans, here is a helpful video.

The TNTvans product is engineered with many mounting locations to give the user the needed flexibility to work with and around the their van floors and walls. Each unit comes with all the hardware the customer needs to mount the units into the van. The install kit comes with your choice of riv nuts, or wood inserts. These are anchors that will create a place to insert a bolt. Plus nuts are for the metal floor in your van. Wood inserts are for a wood floor. Once these anchors are installed, the TNTvans units will bolt into place in just a few minutes.

If desired, the customer may also run a bolt through the supplied hardware kit and floor instead of using an anchor. Our accessories menu has install kits if you want more or if want to change your installation style later down the road.

Yes! I designed the outer frame of each unit with T-track to make it easy for the user to mount their interior wherever they want. If you want to use L-track, Unistrut, or T-track, you can. Once you place your units inside the van you will see where you need your mounting track system to cross your interior unit. Then add your bracket that fits and attach it anywhere to the TNTvans unit.

Yes! TNTvans camper van conversion kits are products that bolt to the floor. Therefore, you can easily install your units now and then come back later to install all of the insulations, windows and van wall liners.

Most customers install anchors into their floors. Each unit can be unbolted from these anchors in just a few minutes.

Yes! We have an authorized TNTvans dealer right here in St. George, Utah. I also offer a Premium "At Your Home" Remote Installation Service. You can purchase these services on the Installation Web Page. Inquire for scheduling.

No. Every piece comes with step by step instructions with large colorful pictures. And if there is any question about the assembly or install, I am available by email, phone, and facetime to help.

Every product I make packs down into a reasonable sized box and will be delivered by UPS. There will be no heavy palleted crates sent to you.

The Bed System was designed to hold multiple adults. The system was originally tested with a family of 4. We then put 600 lbs. of dead weight in the center of two Bed Bridges just to show off how strong it is.

Most units assemble in just under an hour but the Sink System is the most complicated and could take up to 1.5 hours.

For assembly: 2mm hex key, 3 mm hex key, 8mm socket
For van install: 6mm hex key, 3/8" drill bit, drill

AllTNTvans units are framed with thick aluminum material and redundant bracing. There are no screws or wood used in any structural joints. All units are are engineered to be bolted to each other to add extra rigidity to the entire interior system.

Yes! You can easily install more anchors anywhere else in your van and bolt down aTNTvans product. If you want to change your anchors types, you can do that as well. I can mail you additional floor installation kits anytime.

Yes! Everything can un-bolted quickly and re-installed in another van that same day.

It takes about 2 hours to install the anchors for an entire van conversion kit. Once the anchors are installed, you can bolt in your entire kit in less than an hour.

I use CustomCushions.com to order all my cushions. They are USA made and a great company to work with. You can order a cushion through my website or just go straight to them and design your own cushion.

I have a demo van available to see anytime in St. George, Utah.

Yes. Every piece from a camper conversion kit can be bought individually from the products menu.

Most units are between 15 and 40 lbs. with the heaviest being the 51" tall Super Shelving. Most camping conversion kits are under 200 lbs.
